WLT8266BM BLE Module
WLT8266BM is a fully certified(BQB/FCC/CE/SRRC) low cost and low power Bluetooth BLE standard data module designed by Wi-linktech. Module supports BLE (Up to Bluetooth 5.0) . Built-in 512kBFLASH, It also supports hardwareOTA upgrade and multi-boot switch, it's easy to use with optimized AT command software interface.
Content
Typical Application:
Consumer electronics,Smart home,Moto driver,Personal device,BMS,Home appliance
Functional features:
- Built in high performance 32-bit MCU，128KB Flash，16KB SRAM
- Conforming to Bluetooth 4.2 standard，RF link data is up to 2Mbps
- The output power of up to +7dBm
- The reception sensitivity of -92dBm
- Support I2C interface
- Support UART interface
- Support SPI interface
- Support ADC interface
- Support DMIC, AMIC interface
- Support USB interface
- On board high performance PCB antenna
- Support button battery power supply
- The stamp bore the foot and the welding is easy to be reliable
- Ultra small package: 15x17mm
