WLT8016M BLE Module
WLT8016M is a fully certified （BQB/FCC/CE/SRRC）Bluetooth low energy module designed by Wi-linktech. The module support bluetooth 5.1 and BLE mesh, with low power and high sensitivity, It support the open SDK development with engineer friendly development enviroment. The standard firmware support optimized AT command interface with master/slave role software functionality,WLT8016 is a software optimized and easy to use module for IoT application with competitive cost.
Content
Typical Application:
Sports&Health,E-bike, Charging device,Consumer electronics,Moto driver,Smart home
Functional features:
- Built-in high-performance 32-bit MCU, up to 48KB SRAM and 512KB Flash
- Bluetooth 5.0 compliant, Data rates: 2 Mbps, 1 Mbps, 500 Kbps and 125Kbps
- Transmission power: +10 dBm TX power (down to -20 dBm)
- Reception sensitivity: -98 dBm sensitivity in 125 Kbps BLE mode (long range)
- Support UART, SPI, I2C, I2S ,ADC, PWM, etc
- Support for AT command instruction
- Support TRUE Random Number Generator (TRNG) and Hardware AES-128
- cryptographic engine
- 16-bit audio codec with max 50mW PA out
- Board high performance PCB antenna and support external antenna
- Stamp hole pin, easy and reliable welding
- Ultra-small package: 11.2x16mm
- 1.8V-4.3V supply voltage range
- Operating temperature: -40℃~+85℃
